IMASI13 Description​​

The ABB IMASI13 is a high-precision, 16-channel analog input module designed as part of the ABB Bailey and Harmony rack I/O system, often used within the INFI 90 and Symphony Distributed Control System (DCS) environments

. It is engineered for exceptional accuracy and reliability in demanding industrial automation and process control applications. This module excels at acquiring data from a wide variety of sensors, including thermocouples, RTDs (Resistance Temperature Detectors), voltage, and current signals, making it a versatile solution for critical monitoring tasks in industries such as power generation, oil and gas, and chemical processing

​​IMASI13 Features​​

• •

  ​​High Precision & Resolution:​​ Features 24-bit analog-to-digital conversion and independent A/D converters for each channel, providing extremely accurate and repeatable measurements critical for process control

  .

• •

  ​​Multi-Signal Versatility:​​ Supports a vast range of input types on a single module, including various thermocouples (Types E, J, K, etc.), RTDs (Pt100, Pt1000, Ni120, Cu10), millivolt, voltage (0-10V, ±10V), and current (4-20mA) signals, simplifying system design

  .

• •

  ​​Automatic Compensation:​​ Built-in automatic cold junction compensation for thermocouples and lead wire resistance compensation for RTDs enhance measurement accuracy without requiring complex user programming

  .

• •

  ​​Enhanced Diagnostics:​​ Includes built-in diagnostics to monitor the health of the module and connected field devices, facilitating quick troubleshooting and maintenance

  .

• •

  ​​Robust Design:​​ Engineered for high reliability and stable operation in harsh industrial conditions, with a wide operating temperature range and robust construction

  .

• •

  ​​Seamless Integration:​​ Fully compatible with existing ABB INFI 90 and Symphony Enterprise Management Systems, often serving as a direct replacement for older modules like the IMASI03

  .

​​IMASI13 Material & Primary Applications​​

• •

  ​​Material:​​ The module is constructed with industrial-grade materials, typically involving a robust plastic or metal housing for the enclosure and a high-quality printed circuit board assembly inside containing precision electronic components.

• •

  ​​Primary Applications:​​ It is widely used in industries requiring precise and reliable analog signal monitoring

  :
  • •

    ​​Power Generation:​​ Monitoring critical parameters like turbine temperatures and steam pressure

    .

  • •

    ​​Oil & Gas and Chemical Processing:​​ Accurate measurement of process variables such as temperature, pressure, and flow rates

    .

  • •

    ​​Metals and Mining:​​ Monitoring temperatures in furnaces and other critical process points

    .

  • •

    ​​Pulp and Paper and Pharmaceutical:​​ Ensuring precise environmental and process control

    .

​​IMASI13 Key Parameters​​

The following table summarizes the key specifications of the ABB IMASI13 module.
